RF005 cards are contactless cards operating in HF at 13.56 MHz. They comply with the ISO/IEC14443 A standard and transmit data in read/write mode.
Equipped with a 512-bit (64 bytes) EEPROM memory and a unique identifier, these cards also have a programmable read-only block, offering high levels of security.
RF005 cards have anti-collision functionality and can be read at up to 10 cm, which varies depending on the antenna geometry, reader, environment and type of application. Applications include: access control at hotels, companies and educational facilities, and ticketing for public transport.
They are available in three different materials (PVC, PETG and wood) in the following sizes: 86 mm x 54 mm x 0.86 mm for PVC and PETG, 86 mm x 54 mm x 1.3 mm for wood.
| RFID chip | RF005 |
| Chip frequency | 13.56 MHz |
| Memory | 64 Bytes |
| UID | 7 Bytes |
| Manufacturer | Shanghai Fudan Microelectronics |
| ISO Standard | 14443 A |
| NFC Standard | To be verified depending on the reading device |
